Characterization Laboratory
Scanning Electron Microscope (SEM)
Equipped with an energy-dispersive (EDX ) detector
Atomic Force Microscope (AFM)
contact mode
Optical Microscope
Magnification 50 to 500 times
Potentiostat / Electrochemical Impedance
Types of electrochemical tests (ammeter, potentiometry, impedanceو and voltammetry)
Frequency range 10µHz - 8MHz
Maximum voltage ±10V
Maximum current ±2A
Equipped with sunlight simulator
Spectroscopy
UV-Visible-Near IR spectrophotometer
Wavelength range 190 nm to 900 nm and 950 nm to 1800 nm
Applicable for thin films and liquid samples
